4304-2-1 Network Card Settings and Configuration
LANCAST
4304-2-1
Card Type | Transceiver |
NIC Type | Ethernet |
Network Transfer Rate | 10Mbps |
Topology | Star |
Wiring Type | AUI transceiver via DB-15 port, RG-62A/U 93ohm coaxial (2) |
Data Bus | External |
CONNECTIONS | |||
Function | Label | Function | Label |
AUI transceiver via DB-15 | CN1 | RG-62A/U 93ohm coaxial | CN3 |
RG-62A/U 93ohm coaxial | CN2 | ||
USER CONFIGURABLE SETTINGS | ||
Function | Label | Position |
í Signal Quality Error signal disabled (Heartbeat Test Option) | JP1 | Open |
Signal Quality Error signal enabled (Heartbeat Test Option) | JP1 | Closed |
DIAGNOSTIC LED(S) | |||
LED | Color | Status | Condition |
PWR | Green | On | Power is on |
PWR | Green | Off | Power is off |
SQE | Yellow | On | Unit is sending a short collision signal |
SQE | Yellow | Off | Signal Quality Error signal is inactive |
