EN-2000PNP Network Card Settings and Configuration
DANPEX CORPORATION
EN-2000PNP
NIC Type | Ethernet |
Transfer Rate | 10Mbps |
Data Bus | 16-bit ISA |
Topology | Linear Bus/Star |
Wiring Type | Unshielded twisted pair RG-58A/U 50ohm coaxial |
Boot ROM | Available |
DIAGNOSTIC LED(S) | ||
LED | Status | Condition |
LED1 | On | 10Base-T network connection is good |
LED1 | Off | 10Base-T network connection is broken |
LED2 | On | Data is being transmitted/received |
LED2 | Off | Data is not being transmitted/received |
