10BASE-T HUBCARD/4 PC Network Card Settings and Configuration

NIC Type	Ethernet
Transfer Rate	10Mbps
Data Bus	8-bit ISA
Topology	Star
Wiring Type	Unshielded twisted pair
Boot ROM	Not available

MULTIPLE CARD SELECTION
Select	JM1	JM2	JM3	JM4	JM5	JM6	JM7	JM8
Single card	Closed	Open	Open	Closed	Open	Closed	Closed	Open
Multiple cards	Open	Closed	Closed	Open	Closed	Open	Open	Closed
