56PCI-R modem/telephone/ISDN Settings and Configuration

Card Type	Modem/Fax card
Chip Set	Unidentified
Maximum Modem Rate	56Kbps
Maximum Fax Rate	14.4Kbps
Data Modulation Protocol	Bell 103A/212A ITU-T V.21, V.22, V.22bis, V.23, V.32, V.34, V.34bis, K56flex
Fax Modulation Protocol	ITU-T V.17, V.27ter, V.29, V.21CH2
Error Correction/Compression	MNP5, V.42, V.42bis
Fax Class	Class I
Data Bus	PCI

CONNECTIONS
Function	Label		Function		Label
Line out (RJ-11)		CN1		Microphone jack		CN3
Line in (RJ-11)		CN2		Speaker jack		CN4

SUPPORTED COMMAND SET

Basic AT Commands

AT, ‘+++’, A/

A, E, H, M, O, P, V, Z

&C,&W

Special Commands

+MS

S Registers

S0, S1, S2, S3, S4, S5, S6, S7, S8, S9, S10, S11, S12

Note: See MHI Help File for full command documentation.

DATA TERMINAL READY (DTR)
Type:	Configuration
Format:	AT [cmds] &Dn [cmds]
Description:	Selects modem response to DTR
Command	Function
&D0	DTR override
&D1	DTR toggle causes online command mode
í &D2	Normal DTR operations
&D3	Resets on receipt of DTR

DIAL
Type:	Immediate
Format:	AT [cmds] D<#> [cmds]
Description:	Dials telephone number according to any modifiers included in the string
Note:	Any combination of modifiers can be used to produce the desired dial functions in sequence.
Command	Function
DP	Pulse dialing enabled
DT	Tone dialing enabled/Pulse dialing disabled
DW	Dialing resumed following dial tone detection
D^	Data calling tone disabled

FACTORY DEFAULT PROFILE
Type:	Configuration
Format:	AT [cmds] &F [cmds]
Description:	Sets values in active profile to values found in the default profile
Command	Function
&F0	Restore stored profile 0 after warm reset
&F1	Restore stored profile 1 after warm reset

REPORT INFORMATION
Type:	Immediate
Format:	AT [cmds] In [cmds]
Description:	Displays information requested
Command	Function
I0	Reports product code
I1	Reports OK
I2	Tests and reports ROM checksum
I3	Reports modem firmware revision information
I4	Reports OEM identifier string
I6	Reports modem data pump model and internal code revision
