HYPERSTORE-816 Hard Disk/Floppy Controller Settings and Configuration
PERCEPTIVE SOLUTIONS INC.
HYPERSTORE-816
Data bus: 16-bit, ISA
Size: Full-length, full-height card
Hard drives supported: The hS supports MFM, RLL, ESDI, SCSI, or IDE via Mediadapters
Floppy drives supported: Two 360KB, 720KB, 1.2MB, or 1.44MB
Maximum heads/cyl.: 15 heads and 1024 cylinders
CONNECTIONS | |
Functions | Location |
34-pin data cable connector-floppy drive | J4 |
USER CONFIGURABLE SETTINGS | |||
Function | Location | Setting | |
| » | Factory configured - do not alter | JB4/jumpers 1 - 4 | open |
| » | Factory configured - do not alter | JB5/jumper 1 - 4 | open |
| » | BIOS address is C800h | JB5/jumper 5 | closed |
BIOS address is CA00h | JB5/jumper 5 | open | |
| » | Floppy drive port address is 3F2-3F7h | JB6/jumper 1 | open |
Floppy drive port address is 372-377h | JB6/jumper 1 | closed | |
| » | Single speed floppy drive supported | JB6/jumper 2 | open |
Dual speed floppy drive supported | JB6/jumper 2 | closed | |
INTERRUPT REQUEST | |||||
IRQ | JB3/jumper 1 | JB3/jumper 2 | JB3/jumper 3 | JB3/jumper 4 | |
| » | Disabled | open | open | open | open |
IRQ5 | closed | open | open | open | |
IRQ12 | open | closed | open | open | |
IRQ14 | open | open | closed | open | |
IRQ15 | open | open | open | closed | |
CACHE MEMORY CONFIGURATION | ||
Size | Bank 0 | Bank 1 |
512KB | (2) 256K x 9 | NONE |
1MB | (2) 256K x 9 | (2) 256K x 9 |
2MB | (2) 1M x 9 | NONE |
2.5MB | (2) 1M x 9 | 256KB |
